Product Introduction​

The jaw crusher (Jaw Crusher) is a highly efficient primary crushing equipment widely used in industries such as mining, metallurgy, building materials, highways, railways, and water conservancy. It is mainly used for the primary crushing of ores,rocks, and construction waste of various hardness levels. With its simple structure, reliableoperation, and easy maintenance, it is one of the core machines in the crushing field.

Working Principle​​

The jaw crusher is driven by an electric motor that rotates an eccentric shaft, causing the movable jaw to move back and forth periodically. This motion crushes the material between the fixed jaw plate and the movable jaw

plate through compression, splitting, and bending forces. The crushed material is then discharged from the discharge opening, achieving particle size classification.

​​High Efficiency & Energy Saving​​：Optimized crushing chamber design ensures a large crushing ratio, high productivity, and low energy consumption.

​​Durable & Robust​​：Made of high-strength materials, key components (such as jaw plates and bearings) undergo special treatment for extended service life.

​​Flexible Adjustment​​：The discharge opening can be quickly adjusted via shims or a hydraulic system to control the output size.

​​Low Maintenance Cost​​：Simple structure, easy maintenance, and an automated lubrication system.

​​Wide Applicability​​：Capable of processing various materials with compressive strength up to 320 MPa (e.g., granite, basalt, limestone).

Technical Parameters
